| Superior Elector less Nickel plating is an alloy of 10-12% Phosphorus
in Nickel as compared to conventional low content (less than 9%)
of Phosphorus & having advantage of highly corrosion resistance
coating. It is recommended where maximum corrosion protection is
required. Salt Spray Resistance of 1000 Hours as per ASTMB 117 test
can be achieved. There is absolutely no comparison of corrosion
resistance property of Superior Electroless Nickel Plating with
conventional low content of Phosphorus Electroless Nickel Plating. |
 |
| Superior Electorless Nickel Plating is applied wherever a uniform,
hard and highly corrosion resistance coating is required. Its high
hardness and lack of porosity makes it an ideal coating for components
to aggressive usage. The as-plated hardness of Superior Electroless
Nickel Plating is in range of 46 to 48 HRc and can be heat treated
to 66 to 70 HRc for a more wear resistance finish. |
 |
| Because the coating is deposited ”CHEMICALLY” rather
than with electricity, the problems normally associated with electroplating
like edge built-up, uneven thickness and no plating in corners are
avoided. Superior Electroless Nickel Plating deposits guarantee
100% coverage and are so uniform that the surface finish is normally
duplicated and after plating, process kike machining and grinding
is not required. Advantage of this uniformity is that threads and
other complex shapes also maintain their original geometry after
plating. |
 |
- Excellent corrosion resistance property.
- Excellent wear & abrasion resistance property.
- High hardness
up to 70 HRc.
- Coating can be done on any base metal like M.S, C.I, Aluminum,
EN Series, HCHCR, Copper, and Brass etc.
- No costly post treatment like machining and grinding required
because of uniform thickness layer.
- Parts with complex shapes are coated since this process provides
100% coverage with no edge build up.
- Excellent adhesion.
- Low coefficient of friction.
|
 |
| AUTOMOTIVE PARTS |
BEARING |
CAMS |
| DIE |
TEXTILE PARTS |
ELECTRONICS PARTS |
| FOOD PROCESSING PARTS |
FOUNDRY PATTERNS |
GEARS |
| HEAT SINKS |
HYDRAULIC CYLINDERS |
PISTON ROADS |
| PLASTIC MOLDS |
PRINTING ROLLERS |
PUMP SLEEVE |
| ROTORS |
RUBBER MOLDS |
SHAFTS |
| SLIDES |
TAPPINGS |
TABLET PUNCHES |
|
 |
 |
 |
